PCB Cleaners Zestron FA+
Model No: FA+
Boiling range 162-190°C
pH-value (10g/l H2O) 10.4
Cleaning temperature 40-55°C
Flash point 75°C
TDS:  Download

ZESTRON FA+ is a solvent-based cleaning agent designed to remove all types of flux residues from electronic assemblies, ceramic hybrids, power modules and lead frames. The product is characterized by its high cleaning performance and bath loading capability ensuring an extremely long bath life.

 Product Enquiry

Advantages compared to other cleaners:

  • High bath loading capability of ZESTRON® FA+ ensures extended bath life.
  • ZESTRON FA+ is based on non-halogenated, organic solvents.
  • The cleaning medium does not require any specific explosion-proof environment.
  • Due to the surfactant-free formulation, ZESTRON FA+ can be easily rinsed.
  • ZESTRON FA+ can be used for the cleaning of ceramic substrates in thick film applications and for flip-chip applications in the semiconductor industry.
  • ZESTRON FA+ has been EMPF Phase II tested and MIL approved.
  • This cleaning medium is listed in the ESA list of declared materials.

Specification:

Technical Data

Density

(g/ccm) at 20°C/68°F

0.94

Surface tension

(mN/m) at 25°C/77°F

29.7

Boiling range

°C/°F

162 – 190°C / 324– 374°F

Flash point

°C/°F

75°C/167°F

pH-value

10g/l H2O

10.4

Vapor pressure

(mbar) 20°C/68°F

0.47

Cleaning temperature

°C/°F

40 – 55°C / 104 – 131°F

Solubility in water



Soluble

Application concentration 1

Ready to use

Pure

HMIS Rating

Health-Flammability-Reactivity

1 – 2 – 0
