BVX-250 Series
Model No: BVX-250 Series
TDS:  Download

The BVX-250 is a portable, two-station filtration system for removing workplace fumes, smoke, dust, and vapors. With 99.97% efficiency HEPA 13 filtration, 30-second filter changes, and twice the suction power of previous models. Compatible with previous BVX & Omniflex arms and hoses. Arms/hoses are sold separately.

 Product Enquiry

Feature And Benefits

  • Easy 30-Second Filter Changes
  • LED Status Ring
  • 2x the Suction of Previous Models
  • 99.97% Efficiency HEPA 13 Filter
  • Optional Deep Bed Gas Filter (FG-BVX250, sold separately)
  • Quiet Operation
  • Three Power Levels
  • 360-degree Rotating/Removable Air Diverter
  • Communicates with Metcal CV & GT Series Soldering Systems
  • New Circular & Rectangular Nozzles with Nozzle Filters are available
  • Compatible with previous BVX & Omniflex Arms and Hoses
  • Small Footprint for Under or On the Benchtop
  • Remote Switch Included



Product Comprise of

  • BVX-250 Fume Extraction Unit
  • HEPA 13/Gas Main Filter
  • Pre-Filter
  • Remote Switch



Specification

Max. airflow, free blowing

297 m3/h (175 cfm)

Flow rate

2 x 75 m3/h (45 cfm)

Static pressure

1743 Pa (7” WC)

Noise level (approx.)

< 55 dBA (at medium setting)

Voltage

100 – 240 VAC, 1 phase

Frequency

50/60 Hz

Power

150 Watts

Safety compliance

UL & CSA, UKCA, KC, PSE, NOM, CE (ISO-14644), TUV

Dimensions W/D/H mm

268 x 400 x 320

Dimensions W/D/H inches

10.5” x 16” x 13”

Weight (approx.)

12 lbs. / 5.5 kg
